• Latest in design and technology
• New crankcase style
• High strength forged brass manifold for long term use
• NEW ceramic plungers, thicker wall to help prevent thermal shock
• Stainless steel valves
• Side mount valve seat o-rings
• High quality high pressure seals
• NEW low pressure seal with built in scraper
• Two piece piston guides
• NEW connecting rod with 12% more load surface
• Large side cover sight glass
• Oversized bearings
• Rear cover oil drain
• Forged, precision ground crankshaftSpecifications
• Maximum pump speed: 3,400 RPM
• Shaft diameter: 3/4” hollow
• Maximum horsepower requirements: 4.54 GHP
• Maximum fluid temperature: 140°F.
• Inlet ports (2): 1/2" female
• Outlet ports (2): 3/8" female
• Oil capacity: 9.81 oz
• Weight: 11.0 lb.
RCV series pumps are designed to direct drive on gasoline engines ranging from 4-7.5 HP. It's intended use is for medium to heavy duty tasks. This triplex plunger pump features the latest in design and technology.
The pump is life tested at a maximum performance of 3 GPM @ 3000 PSI. The RCV series features a compact body design which makes it a perfect replacement pump for repair shops. The RCV is a result of AR's combined 60 years of pump building experience and expertise.
RCV series pumps are fully rebuild-able, tested to 2000+ hour life and have triplex ceramic plungers and a forged manifold head.
This series fits 3/4" keyway horizontal engines bolts, oil and vented dipstick.
