Features:
• High pressure MUD pump
• Specifically designed to pump mixtures of water, bentonite and/or polymers typical of mining and directional drilling applications
• Patent-pending, symmetrical power end design featuring top and bottom mounting holes allowing for easy left to right shaft conversion
• 17-4 stainless steel valves are guided to promote efficient delivery of fluids
• Seating areas are treated with abrasion resistant material to extend life of wearing surfaces
• Energized packings/seals are produced from high density polyethylene
• Splash lubrication
• Extended crosshead features open design and double oil seals to minimize unwanted collection of drilling fluids.
• Available in hydraulic version
Materials:
• High resistance light alloy crankcase
• Stainless steel manifold, nickel treated
• Tapered roller rim bearings
• Special antifriction, light alloy connecting rods
• Forged alloy steel crankshaft, hardened, tempered and nitrited
• Cast iron piston guide, nickel treated
• Solid ceramic plungers, with ceramic coated Stainless Steel extension
• Valve disks and seats 17/4 Stainless Steel
Common Specifications:
• Maximum Inlet Pressure: 45 PSI
• Maximum Fluid Temperature: 140 ° F
• Inlet Port Thread: 1-1/4" NPT-F
• Discharge Port Thread: 1 " NPT-F
• Shaft Diameter: 1.6"/40 mm
• Stroke: 1.9 "/50 mm
• Pump Dimensions: 23.6" x 10" x 9.9"
• Crankcase Oil Capacity: 124.4 oz. (3.68 liters)
• Shipping Weight: 160 lbs./73 kg
| Manufacturer: | General Pump |
| SKU: | KFM40A |
| Finance Option 1: | 151.93/Month for 48 Months - Click HERE |
| Finance Option 2: | 483.25/month for 13 months - Click HERE |
| Brand: | GENERAL PUMP |
